Hydrocyclone Filter
Premium filtration solutions for industrial and commercial applications
About Hydrocyclone Filter
Looking for a reliable hydrocyclone filter manufacturer in the GCC, USA, Europe, or Southeast Asia? Flometriq is a trusted global supplier of high-performance hydrocyclone filters engineered for superior particle separation and protection of downstream equipment across critical industries.
Proudly manufactured in India and exported worldwide, Flometriq’s hydrocyclone filters are available in a wide range of materials including Stainless Steel, Carbon Steel, Duplex, Super Duplex, and other corrosion-resistant alloys, ensuring reliable performance even in the harshest process conditions. Our hydrocyclone separators are designed to deliver effective solid-liquid separation without the need for moving parts, reducing maintenance costs and enhancing system efficiency.
With over 50 years of filtration expertise and a proven track record in supplying to global projects, Flometriq is the preferred choice for EPC contractors, utilities, irrigation projects, and process industries in key markets such as the UAE, Saudi Arabia, Kuwait, Oman, Qatar, Bahrain, Singapore, Malaysia, Europe, and the United States.
Specifications & Details
Comprehensive information about our hydrocyclone filter systems
HCF-150CL Hydrocyclone Filter Specifications
| Feature | Description |
|---|---|
| Model Name | HCF-150CL Hydrocyclone Filter |
| Filtration Type | Centrifugal solid-liquid separation (no filter media required) |
| Recommended Use | Primary filtration for high-solid, abrasive fluids |
| Material of Construction | Heavy-duty powder-coated carbon steel (custom SS options available) |
| Connection Type | Flanged inlet/outlet (ANSI/DIN compatible) |
| Operating Pressure | 2 to 10 bar (factory-tested for pressure resistance and durability) |
| Flow Range | Designed for medium to high flow systems (up to 120 m³/hr per unit) |
| Separation Efficiency | Up to 90% efficiency for particles >75 microns |
| Drain Mechanism | Manual or automatic purge valve at the bottom cone |
| Maintenance | No internal parts to clean; purge sludge as needed |
| Installation | Vertical mounting; inlet tangential, outlet axial |
| Custom Options | Custom configurations, exotic alloys (Duplex, Super Duplex, Inconel, etc.), and higher pressure ratings available on request |
Applications of Hydrocyclone Filters
Irrigation Systems (Drip/Sprinkler)
Protects emitters and pipelines from clogging due to sand and soil particles in groundwater or surface water.
Flow Conditioning in Tight Spaces
Removes scale, rust, and solids from recirculating cooling water to protect pumps and heat exchangers.
Wastewater Pretreatment
Separates heavy inorganic solids from influent before biological or membrane treatment stages.
Mining and Mineral Processing
Removes suspended solids like silica, tailings, and fine ore from process slurries and wash-down water.
Pulp & Paper Industry
Reduces grit and fiber carryover in return water systems, improving equipment life and water reuse quality.
Sand Trap for RO/UF Plants
Acts as a pre-filter before fine filtration units like cartridge filters or membranes, extending their life.
Stormwater Filtration
Used in infrastructure and drainage systems to prevent sediment buildup and protect pumps and valves.
Chemical & Petrochemical Processing
Prevents debris, scale, and other contaminants from entering sensitive equipment in chemical and petrochemical processes.
Why Choose Avant Tech Hydrocyclone Filter?
Industry-leading expertise and exceptional service quality
State-of-the-Art Facility with In-House Pressure Drop Testing
At Avant Tech we partner with Flometriq Filtration, which operates from a 45,000 sq.ft. world-class combined manufacturing and testing facility equipped with advanced machinery and instrumentation. Our in-house Pressure Drop Testing Lab ensures every strainer is validated for maximum efficiency and reliability under real-world conditions.
Expert Design Team with 30+ Years of Experience
At Avant Tech we partner with Flometriq Filtration, a trusted basket type strainer manufacturer, our design team brings over four decades of expertise in creating innovative and reliable filtration solutions. Whether it's a standard model or a customized design, our team ensures every solution meets the highest industry standards for quality and efficiency.
Exceptional After-Sales Support
Our commitment to customer satisfaction goes beyond delivery. With a dedicated support team, we provide guidance on installation, maintenance, and troubleshooting to ensure the long-term performance of your equipment.
Prompt Delivery
As a leading supplier, we understand the importance of timely delivery for industrial operations. With standard models in stock and an efficient supply chain, we ensure your orders are delivered on time, every time.
Manufacturing Facility Gallery
Explore our state-of-the-art manufacturing facility
Ready to Find the Perfect Hydrocyclone Filter?
Contact our mechanical engineering team to discuss your filtration requirements and get a customized solution.
